Outdoor GYTS+2*4mm² Optical Cable Steel wire 12F
Produktübersicht
Das optische GYTS+2*4mm²-Außenkabel integriert 12 Fasern mit 2 Stromdrähten. Verfügt über wasserabweisendes Design, mechanische Haltbarkeit und gleichzeitige Daten-/Stromübertragung. Ideal für Telekommunikationsnetzwerke, FTTH und Überwachungsprojekte mit kundenspezifischen Längen erhältlich.
Produktanpassungsattribute
Produktname:
Outdoor GYTS+2*4mm² Optisches Kabel Stahldraht 12F
Faseranzahl:
12
Verkleidung:
125 μm
Beschichtung (±5µm):
250 μm
Bündeladerdurchmesser (mm):
2 mm
Lose Rohrmaterial:
PBT/PP
Verstärkung des Kraftträgerzentrums:
Stahldraht/Stahldraht mit PE-Bedeckung
Mantel Mantelmaterial:
MDPE/HDPE
Farbe:
Schwarz
Kabelgewicht (kg/km):
360
Betriebstemperatur:
-20℃~70℃
Fasermarke:
Corning, YOFC, OFS und Draka
Hervorheben:
Outdoor GYTS fiber optic cable
,12F steel wire optical cable
,4mm² armored fiber cable
Grundlegende Eigenschaften
Herkunftsort:
China, Shenzhen
Markenname:
DF/OEM/Nuetral
Zertifizierung:
CE/ROHS/REACH/ISO9001/ISO14001
Modellnummer:
Outdoor GYTS+2*4mm² Optisches Kabel Stahldraht 12F
Immobilienhandel
Min Bestellmenge:
Verhandelbar
Preis:
negotiable denpend on QTY
Verpackung Informationen:
Blisterbox+Karton
Lieferzeit:
5-9 Arbeitstage abhängig von der QTY
Zahlungsbedingungen:
Western Union, T/T, MoneyGram/Paypal
Versorgungsmaterial-Fähigkeit:
1000 Stück/Tag
Produktbeschreibung
Outdoor GYTS+2*4mm² Optical Cable Steel wire 12F
The fibers,250μm,are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound.
The cable core is FRP or metallic strength member( some structures need add PE as bedding layer in the strength member). Electric wires and tubes (and fillers) are stranded around the strength member into a compact and circular cable core. The cable core is filled with the filling compound to protect it from water ingress. After two sides PSP are longitudinally applied over the inner sheath ,the cable is completed with PE or LSZH outer sheath.
Outdoor GYTS+2*4mm² Optical Cable Applications
-
Telecommunications network;
-
Construction of communication base stations in villages, remote areas in cities and towns ;
-
Residential areas and buildings FTTH;
-
Security monitoring project;
-
Others occasion which information together with electric power at the same time.
Outdoor GYTS+2*4mm² Optical Cable Features
-
Good mechanical and temperature performance;
-
Opto and electricity integrated, fully save pipeline resources;
-
Electric and optical cable maintain relatively independent structure, easy to import; export and link when installation;
-
Electricity lines, telephone lines, television lines, network lines, monitor lines and data lines are multi-one network, saves costs;
-
Larger operating temperature range;
-
Larger construction temperature range;
-
Cable diameter and bending radius are small, freely install in small space and compatible with optical signal and electric energy transmission.
Outdoor GYTS+2*4mm² Optical Cable Parameter and Properties
| Optical fiber type | G.652D | G.655 | 50/125um | 62.5/125um | |
|
Attenuation |
@850nm |
... |
... |
≤3.5 dB/km |
≤3.5 dB/km |
|
@1300nm |
... |
... |
≤1.5 dB/km |
≤1.5 dB/km |
|
|
@1310nm |
≤0.36 dB/km | ≤0.40 dB/km |
... |
... |
|
|
@1550nm |
≤0.22 dB/km |
≤0.23dB/km |
... |
... |
|
|
Bandwidth |
@850nm |
... |
... |
≥500 MHz·km |
≥200 MHz·km |
|
@1300nm |
... |
... |
≥1000 MHz·km |
≥600 MHz·km |
|
|
Numerical Aperture |
... |
... |
0.200±0.015NA |
0.275±0.015NA |
|
|
Cable Cut-off Wavelengthλcc |
≤1260nm |
≤1480nm |
... |
... |
|
Outdoor GYTS+2*4mm² Optical Cable Structure
Other Requirements
Length of production optical cable:2000M
Optical cable outer sheath printing specifications, such as:
OPTICAL FIBER CABLE GYTS-12B1.3+2*4MM 12.5 MM/YY 00000M
