CPR 24C Fiber Optic Patch Cord Data Center MPO Fiber Cable

Produktdetails:

Herkunftsort: Shenzhen, China
Markenname: Neutral/OEM/Takfly
Zertifizierung: CE/ROHS/REACH/CPR/ISO9001/ISO14001
Modellnummer: MPO-Verbindungskabel

Zahlung und Versand AGB:

Min Bestellmenge: 1
Preis: Negotiable
Verpackung Informationen: PET-Tasche
Lieferzeit: Tage 3-7working
Zahlungsbedingungen: Western Union, L/C, T/T, Paypal
Versorgungsmaterial-Fähigkeit: 100Pcs/day
Bestpreis Kontakt

Detailinformationen

Kerne: 24 Kerne Faserart: Inspektion und Millimeter
Länge: 1m, 3m, 5m und besonders angefertigt. Kabeldurchmesser: 3.0mm, 4.5mm
Verbindungsstück-Art: MPO Kabel-Jacke: lszh
Kabel-Farbe: Gelb, Aqua, Veilchen, Lindgrün Anwendung: Data Center
Produktname: Optik-MPO Verbindungskabel der Faser- Andere Fanout-Weise: MTP, LC verfügbar

Produkt-Beschreibung

Fiber Optic MPO 24 Cores Patch Cord Data Center MPO-MPO Fiber Cable


Fiber Optic MPO Patch Cord Name:



Fiber Optic 24 Cores MPO-MPO Patch Cord



Fiber Optic MPO Patch Cord Description:

This MPO-MPO Patch Cord is for the 24 Cores, and can do it for SM and MM according to the requirements. Other cores like 8 cores, 12 cores also available.



This type cable diameter is commonly for 3.0mm, and 4.5mm diameter is also available. The MPO patch cord is with very high density, which is widely used in the Data Center with high performance.


Fiber Optic MPO Patch Cord Features:



Precision molded MT ferrule
High precision guide pins for exact alignment
Compact design, up to 4,8,12,24 fibers
IEC 61754-7 Compliant
Cable diameter 3.0mm, and 4.5mm available





Fiber Optic MPO Patch Cord Applications:

  • Telecommunication Networks
  • Active Deviced/Transceiver Interface
  • Gigabit Ethernet
  • CATV, Video and Multimedia
  • Premise Installations
  • Optical Switch interframe connections
  • Data Center

Fiber Optic MPO Patch Cord Specifications:



Item LC,SC,ST,FC.......                                  MPO/MTP
End face type PC,UPC and APC PC and APC
Fiber type SM(G652,G655,G657);MM(OM1-OM5)
Core number 12, 24
Cable Diameter 0.9,2.0,3.0 Mini Round cable:Max4.5mm; Ribbon cable:Max3.0*5.0mm
Insertion loss(dB)  ≤ 0.3 Standard:≤0.35/0.7(Typical/Max) Low Loss:≤0.2/0.35(Typical/Max)
Return loss(Min)

UPC SM:40dB

APC SM:60 dB

PC MM:25 dB

SM: APC:60dB MM: PC:20dB
Test Wavelength (nm) SM:1310/1550 MM:850/1300
Repeatability ≤ 0.1dB
Durability ≤ 0.2dB
Interchangeability ≤ 0.2dB


CPR 24C Fiber Optic Patch Cord Data Center MPO Fiber Cable 0

CPR 24C Fiber Optic Patch Cord Data Center MPO Fiber Cable 1


Why choose TAKFLY--Advantages as follows:
Professional manufacturer:

  • With more than 21 years manufacturing experience in Fiber optic products;
  • More than 450 assembly workers with 3 years experienced;
  • More than 10 R&D Engineers;
  • 16 Sets Germany imported Injection Machine and 16 Production Lines;
  • More than 30 sets of Testing Machines: OTDR,3D,VFL,IL&RL test instrument; tension strenth tester, Crush Resistance tester, Power meter tester, light checker, ect.
  • OEM Brand is acceptable.
  • Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia ,Global Soure Electronic Exhibition,etc.

Quality Control:

  • Spot check the raw material incoming inspection before production;
  • Fully check after every individual process finished;
  • Fully check production half done;
  • Fully check the finished products before packing;
  • Spot check before shipping;

Delivery:

  • Samples: 1-3 working days.
  • Mass Production Order: 3-7 working days.
  • Packaging: Plastic Bag, Carton and Pallet are available according to your request.

Price: If your QTY is big, the price could be negotiated.
